ELX200 serien består av meget prisgunstige aktive og passive høyttalere i solid konstruksjon som egner seg både for mobil bruk og installasjon. Mulighet for bluetooth styring/kontroll via QuickSmart App.
▪EV QuickSmart Mobile application: quickly andwirelessly configure, control and monitor up to sixELX200 loudspeakers simultaneously, and receiveimmediate notification during critical performanceconditions. Bluetooth® is available in select countries.
▪QuickSmartDSP features best-in-class processing.Easy setup via four presets, sub/top system-match,three-band EQ, five user-programmable presets,visual monitoring of limiter status, input levelcontrol and meters, and master volume control tooptimize gain structure, all via LCD.
▪High-efficiency 1200 W Class-D power amplifierdelivers up to 130 dB peak SPL utilizing transducersdesigned and engineered by EV.
▪EV-patented Signal Synchronized Transducers (SST)waveguide design provides precise and consistentcoverage, minimal distortion, and maximizedacoustical loading.
▪Professional-grade hardware: three M10 threadedmounting points for forged eyebolts, integratedpole-mounts and the proven ZLX three-handledesign for easy lifting.
Frequency response (-3 dB):57 Hz – 16 kHz1
Frequency range (-10 dB):51 Hz – 20 kHz1
Maximum SPL:130 dB2
Coverage (H x V):90° x 60°
Power rating:1200 W
LF transducer:EVS-12M 300 mm (12 in)
HF transducer:DH-1C 1-inch titaniumcompression driver
Crossover frequency:1700 Hz
Connectors:(1) Stereo RCA Input, (2)XLR/TRS combo jack, and (1)XLR
Enclosure:Polypropylene
Grille:18 AWG steel with powdercoat
Suspension:(3) M10 suspension points
Color:Black
Dimensions (H x W x D):629 mm x 363 mm x 344 mm (24.8 in x 14.3 in x 13.6 in)
Net weight:15.6 kg (34.4 lb)
Shipping weight:17.7 kg (39.1 lb)
Power consumption:100 - 240 V~, 50 - 60 Hz, 1.8A3
1: Full space measurement using music DSP preset.
2: Maximum SPL is measured at 1 m using broadbandpink noise at maximum output.
3: Current rating is 1/8 power.
